 Vacuum Emulsifying Tank

Equipment Purpose and Characteristics

The vacuum emulsifying tank is a shear mixing machine integrating high-speed emulsification and mixing stirring. Widely used in industries such as fine chemicals, pharmaceuticals, and dairy foods, its main purpose is to cut neutral particles or fibers into smaller molecules through a specially designed shearer to achieve the required process effects. It is particularly suitable for stable homogeneous emulsification, and the particles produced after high-speed operation are extremely fine.



The emulsification quality depends on the particle dispersion method and size during the preparation stage. The smaller the particles, the weaker the tendency to aggregate on the surface, thus reducing the probability of emulsification breakdown. By relying on the mixing action of forward and reverse rotating blades, homogeneous turbines, and vacuum processing conditions, high-quality emulsification and mixing effects can be obtained.

Product Models

The vacuum emulsifying machine is designed by our company by introducing advanced foreign technologies, specifically for fine chemicals such as cosmetics, toothpaste, and ointments. In recent years, with the rapid development of traditional Chinese medicine and dairy food industries in China, our company has successively researched and designed the following models with different specifications based on customer requirements and the diverse properties of various materials, aiming to meet the needs of customers with different demands.

Special Emulsifying Machine for Biological Pharmaceuticals

Designed meticulously according to the process requirements of experts from biological pharmaceutical enterprises, this machine features fully automatic control and is exclusively used for biochemical pharmaceutical production.

2. Special Emulsifying Machine for Traditional Chinese Medicine Ointments

Specifically designed for traditional Chinese medicine preparations and ointment production, this machine is available in two types: semi-automatic control and fully automatic control.

3. Special Emulsifying Machine for Dairy Foods

Dedicated to emulsification and mixing of dairy foods, it can be widely used for shearing and emulsification of fresh lactic acid milk, as well as ingredient emulsification and mixing in food and health products.

Main Specifications and Parameters

Specification Model Overall Dimensions (mm) Total Power Remarks
Electric Heating Steam Heating
ZYRHQ-5 1080×700×1100×1500 3.09KW 1.09KW
980×600×990
ZYRHQ-10 1100×700×1200×1600 4.2KW 2.2KW
1050×600×1100
ZYRHQ-20 1300×500×1560×2360 16.57KW 7.57KW
1200×510×1200
ZYRHQ-50 1800×700×1880×2600 23KW 8KW
1300×560×1280
ZYRHQ-100 1900×800×2040×2800 29KW 11KW
1500×990×1500
ZYRHQ-150 2430×900×2320×3200 35KW 11KW
1600×1060×1500
ZYRHQ-200 2480×1000×2380×3300 36KW 12KW
1700×1210×1550
ZYRHQ-300 2500×1000×2420×3470 44KW 14KW
1940×1540×1700
ZYRHQ-350 2600×1100×1440×3500 45.75KW 15.75KW
1940×1540×1750
ZYRHQ-500 3000×1200×2750×3750 57.5KW 21.5KW
2180×1680×1780
ZYRHQ-750 3200×1400×3100×4500 67KW 25KW
2350×1750×1880
ZYRHQ-1000 3300×1500×3100×4560 79KW 28KW
2860×2160×2300
ZYRHQ-1500 4500×2900×3900×5400 35.2KW
4500×2180×3750
ZYRHQ-2000 4580×3070×4010×5510 32KW
4580×2280×3820
ZYRHQ-3000 4780×3350×42 4780×3350×4280×5750 27.5KW
4780×2550×4200
ZYRHQ-4000 5000×3520×4545×6450 25KW
5000×2730×4300
