High-speed disperser is a stirring device that uses a high-speed dispersing disk as the stirring system.
High-speed disperser is a stirring device that uses a high-speed dispersing disk as the stirring system. The speed is 0 to 1450 rpm, which is adjustable and can achieve low-speed, high-speed, and medium-high-speed dispersion. The design the dispersing disk is based on the viscosity and tension of the material. Through high-speed sawtooth stirring, the material can be dispersed, mixed, crushed, andogenized. When mixing and dispersing, the high-speed disperser has very little air retention, and the mixing and uniformity effects are excellent. Using medium and high- stirring and dispersing can quickly dissolve materials and reduce particle size.
The significant advantage of the high-speed disperser is that it integrates dispersion, mixing, emulsification,ogenization, and crushing functions. It has the characteristics of ultra-fine stirring, stable material after stirring, high stirring efficiency, and good dissolution effect. The high-speeder can be made in a split or integrated structure. The form to be used can be selected according to the process characteristics.
Regardless of whether it is a split or high-speed disperser, the tank body is made of high-quality stainless steel plates. The material contact part is made of S30408 (referred to 304) or S31603 (referred to as 316L) stainless steel. The inner and outer surfaces of the tank body are and polished, and the outer surface is treated with matte finish. The welds at the joints are polished smooth and polished.
The high-speed cutting disperser can mix andperse cut solid and liquid raw materials under the powerful force of 1450 rpm per minute, which reduces the time of low-speed stirring, saves energy, and shortens the production cycle. Moreover, the frequency conversion speed regulation is adopted. If you want to use low-speed stirring, you can switch and adjust to the low-speed state.
The high-speed disperser adopts electromagnetic speed regulation or frequency conversion speed regulation, which can start with low-speed stirring. When the material does not foam much gradually adjust the speed.
The high-speed disperser equipped with a hydraulic lifting device or a mechanical lifting device can be used for tanks of various sizes and can be and quickly moved up and down.
According to the process needs, the high shear disperser can also be combined with other stirring forms and can adopt various stirring paddle forms, can be applied to the production of different types of products; the paddle can choose a frame scraper paddle, a blade scrapper paddle, a propeller, a three-bl propeller paddle or an anchor paddle or emulsifying head.
The high shear disperser can also be designed with a pressure tank according to the production process requirements, equipped a vacuum pump, and vacuum foaming, vacuum dispersion, etc.
